Does spray paint room handle waste gas what to facility need?

The near future, the client that has a lot of places calls will refer a question, that is: Does off-gas treatment need spray paint room what equipment? How many money? To answer this question of the client, company of grand rich environmental protection is small write an article, introduce the facility that off-gas treatment needs spray paint room technically, the purpose is to let a client there is an abecedarian knowledge when choosing environmental protection equipment, unapt after the furnish that be installed by flicker of a lot of companies has also short of effect, be client consider just should do manufacturer of environmental protection equipment.

Application of spray paint room is very wide, very small component also needs spray paint, if spray paint cannot be in,open air is operated, need is in airtight spray paint room or spray paint automation line, in the spray paint waste gas that these places produce, undertake with respect to need waste gas is collected, after coming to waste gas gather up to purify, discharge again.

Off-gas treatment needs spray paint room what equipment

SomeSpray paint roomTake water shade cabinet oneself, water shade ark basically filters paint grain content, enter dissolve of paint grain content water in, fixed arrangement personnel salvages lacquer broken bits, in water shade dry type is added to filter behind ark box, dry type filters box the configuration inside basically is to hold back water shade ark or the lunt that gush drenchs the tower comes and grain content, stop lunt and grain thing come down, prevent to enter below one process, below one working procedure can be catalytic combustion equipment, also can be equipment of smooth oxygen catalysis, or box of activated carbon adsorption, it is to use those who purify organic waste gas.

Spray paint room one of off-gas treatment technological process are to use: Gather device — >> pay conduit — >> the hand moves air-valve — >> the director — >> water gush drenchs — >> equipment of smooth oxygen catalysis / device of activated carbon adsorption — >> frequency conversion fan — >> chimney discharges; from ground 15m headroom

Spray paint room of off-gas treatment technological process is to use: Gather device — >> pay conduit — >> the hand moves air-valve — >> the director — >> water gush drenchs — >> dry type filters box — >> catalytic combustion equipment — >> frequency conversion fan — >> chimney is discharged from ground 15m headroom.

After off-gas treatment equipment installs spray paint room

The waste gas that has produced spray paint above all introduces through paying conduit in director path, raising the installation on conduit to have air-valve, with will adjust wind force, prevent to absorb wind effect not all with perhaps attract immobile circumstance generation, introduce gush to drench next in purifying a tower, drench through gush the water mist that purifies tower interior, qi Wu grain content dissolve enters water in, can the grain content of purify 40~70% , reentrance the 2nd gush drenchs and demist implement, in device of smooth oxygen catalysis introducing after filtering paint grain content, the network of titanium dioxide smooth accelerant that carries interior of equipment of smooth oxygen catalysis and lamplight of Uv double wave band, decompose make the part such as hurtless carbon dioxide and lunt, amount to mark to discharge through 15 meters of chimney finally.

What off-gas treatment installation sets spray paint room to need to notice fully is:

1, pressing negative pressure issue: Commendatory method is negative pressure means, namely fan installs advanced end, photograph of processor interior pressure is negative pressure to atmosphere. Negative pressure means has a variety of profit, for example, air stream is steady, without flat, effect photograph is advanced to be being carried somewhat at be being pressed. Pressing just can use below special situation only, install characteristic for example, field the; such as limitation

2, flexible connection and fan must pass flexible connection, basically consider oscillatory problem;

3, fan foundation and processor foundation: Processor foundation should assure to fight wind function only can, without special requirement, fan foundation must accord with installation standard, should notice resonance problem; particularly

4, wind block problem: Because the design basically uses low speed pipeline, need not consider wind block; overly so but the pressure that every bend wants to increase 50 handkerchief, answer because of this conduit as far as possible flat installation;

5, filter the effect of problem filter is very main to the project, must give take seriously. Especially the wind block of filter, should be in spot actual measurement, too large wind block can cause ventilation to be not worth; measurement technique to use much dot numeration.

Is above content we handle waste gas what to facility need about spray paint room? The introduction that make, if you think understanding is more,can pay close attention to our follow-up to still more and wonderful data is waiting for you to understand about the data of spray paint room.
